create a dlhdl.processorconfig object.

hpc = dlhdl.processorconfig;

set up the tool path to your design tool. for example, to set up the path to the vivado^® design tool, enter:

hdlsetuptoolpath('toolname','xilinx vivado','toolpath','c:\xilinx\vivado\2020.2\bin\vivado.bat');

generate the custom bitstream.

dlhdl.buildprocessor(hpc);

locate the bitstream file and associated mat file at cwd\dlhdl_prj\, where cwd is your current working folder. the name of the bitstream file is dlprocessor.bit . the name of the mat file is dlprocessor.mat.

to use the generated bitstream for the supported xilinx^® boards, copy the dlprocessor.bit and dlprocessor.mat files to the present working folder.

to use the generated bitstream for the supported intel^® boards, copy the dlprocessor.core.rbf, dlprocessor.mat, dlprocessor.periph.rbf, and dlprocessor.sof files to the same present working folder.

deploy the custom bitstream and deep learning network to your target device.

htarget = dlhdl.target('xilinx');
net = resnet18;
hw = dlhdl.workflow('network',net,'bitstream','dlprocessor.bit','target',htarget);
% if your custom bitstream files are in a different folder, use:
% hw = dlhdl.workflow('network',snet,'bitstream',...
% 'c:\yourfolder\dlprocessor.bit','target',htarget);
hw.compile;
hw.deploy;
