satellite scenario

since r2021a

description

the satellitescenario object represents a 3d arena consisting of satellites, ground stations, and the interactions between them. use this object to model satellite constellations, model ground station networks, perform access analyses between the satellites and the ground stations, and visualize the results.

creation

syntax

sc = satellitescenario

sc = satellitescenario(starttime,stoptime,sampletime)

sc = satellitescenario(___,autosimulate=false)

description

example

sc = satellitescenario creates a default satellite scenario object.

example

sc = satellitescenario(starttime,stoptime,sampletime) sets the starttime, stoptime, and sampletime properties to the values of starttime, stoptime, and sampletime, respectively.

example

sc = satellitescenario(___,autosimulate=false) sets the autosimulate property to a specified value.

properties

`starttime` — start time of satellite scenario simulation in utc
`datetime` scalar

start time of the satellite scenario simulation in utc, specified as a scalar.

the default starttime is the current utc time if no satellites are present in the scenario. otherwise, it is the earliest value among

the current utc time.
the epoch defined in the tle files.
the reference time deduced from the gps week number defined in sem files.
the earliest time deduced from rinex navigation data for gps and galileo.
the initial time in the timetable and timeseries.

if the starttime, stoptime, or sampletime properties are explicitly specified, the starttime property no longer updates with further additions of satellites.

when the autosimulate property is false, you can modify the starttime property only when the simulationstatus is notstarted. you can use the function to reset simulationstatus to notstarted, but doing so erases the simulation data.

data types: datetime

`stoptime` — stop time of satellite scenario simulation in utc
`datetime` scalar

stop time of the satellite scenario simulation in utc, specified as a scalar. the default stoptime is starttime longest orbital period among the satellites in the scenario. if no satellites are added to the scenario, the default stoptime is the same as the default starttime. if the starttime, stoptime, or sampletime properties are explicitly specified, the stoptime property no longer updates with further additions of satellites.

when the autosimulate property is false, you can modify the stoptime property only when the simulationstatus is notstarted. you can use the function to reset simulationstatus to notstarted, but doing so erases the simulation data.

data types: datetime

`sampletime` — sample time of satellite scenario simulation
scalar

sample time of the satellite scenario simulation, specified as a real-valued scalar. the default sample time is set such that there are 100 samples between starttime and stoptime. if the default starttime and stoptime are the same, which is the case when no satellites are added to the scenario, the default sampletime is 60 seconds. if the starttime, stoptime, or sampletime properties are explicitly specified, the sampletime property no longer updates with further additions of satellites.

when the autosimulate property is false, you can modify the sampletime property only when the simulationstatus is notstarted. you can use the function to reset simulationstatus to notstarted, but doing so erases the simulation data.

data types: double

`simulationtime` — simulation time of satellite scenario in utc
current utc time (default) | `datetime` scalar

this property is read-only.

current simulation time of the satellite scenario simulation in utc, specified as a scalar. call the function to reset the time to starttime.

dependencies

to enable this property, set autosimulate to false.

data types: datetime

`simulationstatus` — simulation status
`'notstarted'` (default) | `'inprogress'` | `'completed'`

this property is read-only.

simulation status of the satellite scenario, specified as one of the following:

'notstarted' — no call to the function has been made
'inprogress' — simulation is running
'completed' — simulation is finished

the simulation starts when the first call to the function is made. the simulation continues until one of the following occurs:

the simulation reaches the stoptime.
a new asset is added to the satellite scenario.
certain properties of the asset (satellites, ground stations, gimbals, conical sensors, and so on) have been modified, such as mountinglocation or mountingangles. refer to the properties to determine if modifying them can stop the simulation.

call the function to restart the simulation, erase the simulation data, and set simulationstatus to notstarted.

dependencies

to enable this property, set autosimulate to false.

`autosimulate` — option to simulate satellite scenario automatically
`true` or `1` (default) | `false` or `0`

option to simulate the satellite scenario automatically, specified as one of these numeric or logical values.

1 (true) — simulate the satellite scenario automatically on any call to an analysis function, such as states or accessintervals.
0 (false)— simulate the satellite scenario only by calling the function.

changing the autosimulate value erases the previous simulation data.

data types: double

`satellites` — satellites in the scenario
row vector of `satellite` objects

satellites in the scenario, returned as a row vector of objects. to create a object and add it to the satellite scenario, use the object function. after adding satellites to the scenario, this property is read-only.

`groundstations` — ground stations in scenario
row vector of `groundstation` objects

ground stations in the scenario, returned as a row vector of objects. to create a object and add it to the satellite scenario, use the object function. after adding ground stations to the scenario, this property is read-only.

`autoshow` — option to automatically show graphics
`true` or `1` (default) | `false` or `0`

option to automatically show graphics, specified as a logical 1 (true) or 0 (false). this property determines if entities added to the scenario are automatically shown in an open window.

object functions

	add ground station to satellite scenario
	add satellites to satellite scenario
	create viewer for satellite scenario
	move simulation forward by one sample time
	restart simulation from beginning
	play satellite scenario simulation results on viewer
	create walker-delta constellation in satellite scenario
	create walker-star constellation in satellite scenario

examples

create satellite scenario with custom start and stop times

specify the start time in the current time zone as yesterday. the simulation lasts for half a day.

starttime = datetime("yesterday","timezone","local");
stoptime = starttime   days(0.5);

specify the sample time as 60 seconds. create a satellite scenario object, specifying the start time, stop time, and sample time.

sampletime = 60;
sc = satellitescenario(starttime,stoptime,sampletime)

sc =
  satellitescenario with properties:
         starttime: 02-mar-2023 05:00:00
          stoptime: 02-mar-2023 17:00:00
        sampletime: 60
      autosimulate: 1
        satellites: [1x0 matlabshared.satellitescenario.satellite]
    groundstations: [1x0 matlabshared.satellitescenario.groundstation]
           viewers: [0x0 matlabshared.satellitescenario.viewer]
          autoshow: 1

add satellites to scenario using keplerian elements

create a satellite scenario with a start time of 02-june-2020 8:23:00 am utc, and the stop time set to one day later. set the simulation sample time to 60 seconds.

starttime = datetime(2020,6,02,8,23,0);
stoptime = starttime   days(1);
sampletime = 60;
sc = satellitescenario(starttime,stoptime,sampletime);

add two satellites to the scenario using their keplerian elements.

semimajoraxis = [10000000;15000000];
eccentricity = [0.01;0.02];
inclination = [0;10];
rightascensionofascendingnode = [0;15];
argumentofperiapsis = [0;30];
trueanomaly = [0;20];
sat = satellite(sc,semimajoraxis,eccentricity,inclination, ...
    rightascensionofascendingnode,argumentofperiapsis,trueanomaly)

sat =
  1x2 satellite array with properties:
    name
    id
    conicalsensors
    gimbals
    transmitters
    receivers
    accesses
    groundtrack
    orbit
    orbitpropagator
    markercolor
    markersize
    showlabel
    labelfontcolor
    labelfontsize

view the satellites in orbit and the ground tracks over one hour.

show(sat)
groundtrack(sat,leadtime=3600)

ans=1×2 object
  1×2 groundtrack array with properties:
    leadtime
    trailtime
    linewidth
    leadlinecolor
    traillinecolor
    visibilitymode

play the scenario and set the animation speed of the simulation to 40.

play(sc,playbackspeedmultiplier=40)

manual simulation of satellite scenario

create a satellite scenario object and set the autosimulate property to false to enable manual simulation of the satellite scenario.

starttime = datetime(2022,1,12);
stoptime = starttime   days(0.5);
sampletime = 60;                             % seconds
sc = satellitescenario('autosimulate',false);

add a gps satellite constellation to the scenario.

sat = satellite(sc,"gpsalmanac.txt");

simulate the scenario using the advance function.

while advance(sc)
end

obtain the satellite position histories.

p = states(sat);

autosimulate is false, so restart the scenario before adding a ground station.

restart(sc);

add a ground station to the scenario.

gs = groundstation(sc);

add access analysis between each satellite and ground station.

ac = access(sat,gs);

simulate the scenario and determine the access intervals.

while advance(sc)
end
intvls1 = accessintervals(ac)

intvls1=35×8 table
     source           target           intervalnumber         starttime                endtime           duration    startorbit    endorbit
    ________    ___________________    ______________    ____________________    ____________________    ________    __________    ________
    "prn:1"     "ground station 32"          1           11-jan-2020 23:20:25    12-jan-2020 05:15:47      21322        nan          nan
    "prn:2"     "ground station 32"          1           12-jan-2020 04:03:16    12-jan-2020 07:40:50      13055        nan          nan
    "prn:3"     "ground station 32"          1           11-jan-2020 19:50:06    11-jan-2020 21:38:53     6527.3        nan          nan
    "prn:3"     "ground station 32"          2           12-jan-2020 01:52:43    12-jan-2020 06:42:49      17406        nan          nan
    "prn:4"     "ground station 32"          1           11-jan-2020 19:50:06    12-jan-2020 00:11:11      15665        nan          nan
    "prn:4"     "ground station 32"          2           12-jan-2020 04:54:02    12-jan-2020 07:40:50      10008        nan          nan
    "prn:5"     "ground station 32"          1           12-jan-2020 05:52:03    12-jan-2020 07:40:50     6527.3        nan          nan
    "prn:6"     "ground station 32"          1           12-jan-2020 02:43:29    12-jan-2020 07:40:50      17841        nan          nan
    "prn:7"     "ground station 32"          1           11-jan-2020 21:09:52    12-jan-2020 03:27:00      22628        nan          nan
    "prn:8"     "ground station 32"          1           11-jan-2020 20:33:36    12-jan-2020 03:19:45      24369        nan          nan
    "prn:9"     "ground station 32"          1           11-jan-2020 19:50:06    12-jan-2020 00:47:27      17841        nan          nan
    "prn:9"     "ground station 32"          2           12-jan-2020 05:08:32    12-jan-2020 07:40:50     9138.2        nan          nan
    "prn:10"    "ground station 32"          1           12-jan-2020 00:32:56    12-jan-2020 01:59:58     5221.8        nan          nan
    "prn:11"    "ground station 32"          1           11-jan-2020 22:15:09    12-jan-2020 04:39:32      23063        nan          nan
    "prn:12"    "ground station 32"          1           12-jan-2020 04:32:16    12-jan-2020 07:40:50      11314        nan          nan
    "prn:13"    "ground station 32"          1           12-jan-2020 00:03:56    12-jan-2020 02:50:44      10008        nan          nan
      ⋮

visualize the simulation results.

v = satellitescenarioviewer(sc,'showdetails',false);
play(sc);

verify that the access intervals are the same when you set the autosimulate property to true.

sc.autosimulate = true;
intvls2 = accessintervals(ac)

intvls2=35×8 table
     source           target           intervalnumber         starttime                endtime           duration    startorbit    endorbit
    ________    ___________________    ______________    ____________________    ____________________    ________    __________    ________
    "prn:1"     "ground station 32"          1           11-jan-2020 23:20:25    12-jan-2020 05:15:47      21322        nan          nan
    "prn:2"     "ground station 32"          1           12-jan-2020 04:03:16    12-jan-2020 07:48:06      13490        nan          nan
    "prn:3"     "ground station 32"          1           11-jan-2020 19:50:06    11-jan-2020 21:38:53     6527.3        nan          nan
    "prn:3"     "ground station 32"          2           12-jan-2020 01:52:43    12-jan-2020 06:42:49      17406        nan          nan
    "prn:4"     "ground station 32"          1           11-jan-2020 19:50:06    12-jan-2020 00:11:11      15665        nan          nan
    "prn:4"     "ground station 32"          2           12-jan-2020 04:54:02    12-jan-2020 07:48:06      10444        nan          nan
    "prn:5"     "ground station 32"          1           12-jan-2020 05:52:03    12-jan-2020 07:48:06     6962.4        nan          nan
    "prn:6"     "ground station 32"          1           12-jan-2020 02:43:29    12-jan-2020 07:48:06      18276        nan          nan
    "prn:7"     "ground station 32"          1           11-jan-2020 21:09:52    12-jan-2020 03:27:00      22628        nan          nan
    "prn:8"     "ground station 32"          1           11-jan-2020 20:33:36    12-jan-2020 03:19:45      24369        nan          nan
    "prn:9"     "ground station 32"          1           11-jan-2020 19:50:06    12-jan-2020 00:47:27      17841        nan          nan
    "prn:9"     "ground station 32"          2           12-jan-2020 05:08:32    12-jan-2020 07:48:06     9573.3        nan          nan
    "prn:10"    "ground station 32"          1           12-jan-2020 00:32:56    12-jan-2020 01:59:58     5221.8        nan          nan
    "prn:11"    "ground station 32"          1           11-jan-2020 22:15:09    12-jan-2020 04:39:32      23063        nan          nan
    "prn:12"    "ground station 32"          1           12-jan-2020 04:32:16    12-jan-2020 07:48:06      11749        nan          nan
    "prn:13"    "ground station 32"          1           12-jan-2020 00:03:56    12-jan-2020 02:50:44      10008        nan          nan
      ⋮

visualize the scenario.

play(sc);

tips

when saving the satellite scenario, either save the entire workspace containing the scenario object or save the scenario object itself.

version history

introduced in r2021a

satellite scenario -pg电子麻将胡了

description

creation

syntax

description

properties

`starttime` — start time of satellite scenario simulation in utc
`datetime` scalar

`stoptime` — stop time of satellite scenario simulation in utc
`datetime` scalar

`sampletime` — sample time of satellite scenario simulation
scalar

`simulationtime` — simulation time of satellite scenario in utc
current utc time (default) | `datetime` scalar

dependencies

`simulationstatus` — simulation status
`'notstarted'` (default) | `'inprogress'` | `'completed'`

dependencies

`autosimulate` — option to simulate satellite scenario automatically
`true` or `1` (default) | `false` or `0`

`satellites` — satellites in the scenario
row vector of `satellite` objects

`groundstations` — ground stations in scenario
row vector of `groundstation` objects

`autoshow` — option to automatically show graphics
`true` or `1` (default) | `false` or `0`

object functions

examples

create satellite scenario with custom start and stop times

add satellites to scenario using keplerian elements

manual simulation of satellite scenario

tips

version history

see also

objects

functions

topics

satellite scenario -pg电子麻将胡了

description

creation

syntax

description

properties

starttime — start time of satellite scenario simulation in utc datetime scalar

stoptime — stop time of satellite scenario simulation in utc datetime scalar

sampletime — sample time of satellite scenario simulation scalar

simulationtime — simulation time of satellite scenario in utc current utc time (default) | datetime scalar

dependencies

simulationstatus — simulation status 'notstarted' (default) | 'inprogress' | 'completed'

dependencies

autosimulate — option to simulate satellite scenario automatically true or 1 (default) | false or 0

satellites — satellites in the scenario row vector of satellite objects

groundstations — ground stations in scenario row vector of groundstation objects

autoshow — option to automatically show graphics true or 1 (default) | false or 0

object functions

examples

create satellite scenario with custom start and stop times

add satellites to scenario using keplerian elements

manual simulation of satellite scenario

tips

version history

see also

objects

functions

topics

wechat

`starttime` — start time of satellite scenario simulation in utc
`datetime` scalar

`stoptime` — stop time of satellite scenario simulation in utc
`datetime` scalar

`sampletime` — sample time of satellite scenario simulation
scalar

`simulationtime` — simulation time of satellite scenario in utc
current utc time (default) | `datetime` scalar

`simulationstatus` — simulation status
`'notstarted'` (default) | `'inprogress'` | `'completed'`

`autosimulate` — option to simulate satellite scenario automatically
`true` or `1` (default) | `false` or `0`

`satellites` — satellites in the scenario
row vector of `satellite` objects

`groundstations` — ground stations in scenario
row vector of `groundstation` objects

`autoshow` — option to automatically show graphics
`true` or `1` (default) | `false` or `0`
